high frequency Portable DC mig 160 amp portable mig welder

FOB Reference Price:Get Latest Price
US $112-112.5 / Sets | 1 Set/Sets MIG/MMA welder (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
eDON MIG/MMA welder
Model Number:
MIG/MMA Welder (ExpertMIG-160)
Wire Feeding Speed:
Adjustable
Dimensions:
500*240*380
Weight:
12.9KG
Usage:
welding
Voltage:
220V 10%
Power(W):
5.6KVA
Certification:
CE,CCC,ISO9001
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Welding:
inverter
MIG/MAG:
CO2 shield
MIG/MMA:
Welding
welder:
single phase
welding equipment:
MIG
inverter welding machine:
IGBT
welding machine:
portable
Supply Ability
Supply Ability:
10000 Set/Sets per Month MIG/MMA welder
Packaging & Delivery
Packaging Details
one MIG/MMA welder in one PLYWOOD BOX OR CARTON WITH FOAM PLASTIC GUARD.
Port
NINGBO/SHANGHAI
Lead Time :
30 DAYS produce mig/mma welder AFTER 30% IN ADVANCE



high frequency Portable DC mig 160 amp portable mig welder



Introduction



Features:



IGBT inverter technology ,energy saving.



Digitial display to view the power anytime during working.



MIG/MMA multifunctions.



Over-current and over-heating protection.



Gas/Gasless use.



Wire feeding speed adjustable.





Parameter:

ITEMMIG-160MIG-180
Rated input voltage(V)1P AC 220V±10%,50/60HZ
Rated input power(KVA)5.65.86.76.8
Rated input Current(A)25.826.332.329
Rated output current &voltage160A/22V140A/25.6V180A/26.5V160A/26.4
Output current(A)50-16020-14050-18020-160
No-load voltage(V)52±552±552±552±5
Rated Duty Cycle (%)6060
Efficiency(%)8585
Power factor(cos)0.730.73
Protection ClassIP21SIP21S
Insulation classFF
Net weight(KG)12.913.2
Dimension(mm)500*240*380500*240*380












SUPER ARC-160-3
